Tang Mega 60K Dock
2024-09-07
Update history
Date | Version | Author | Update content |
---|---|---|---|
06-26-2024 | v0.1 | Serika |
|
Overview
Date to Release: July xx, 2024
TBD
aliexpress purchase link: Click me
Board Features
- Medium capacity LUT4
- Medium capacity memory
- PCIe 2.0 x 4
- USB3.0 x 1
- MIPI C-PHY & D-PHY RX/TX
- TBD
Product Appearance
TBD
Block Diagram
TBD
Hardware Parameters
SOM Board Parameters
Item | Parameter | Supplement | ||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
FPGA Chip | GW5AT-LV60PG484A |
|
||||||||||||||||||||||||||||||||||||
Memory | 4Gb DDR3 | 512MB x 1 | ||||||||||||||||||||||||||||||||||||
Flash | 128Mbits Flash x 1 | See How to Burn to Flash | ||||||||||||||||||||||||||||||||||||
Debug Interface | Jtag + Uart | JST SH1.0 8Pins CONN. | ||||||||||||||||||||||||||||||||||||
Overall Package | 35mm x 45mm Size | BTB CONN. Connects the SOM and the Dock Board |
Dock board Parameters
TBD
Hardware Resources
Getting Started
Note that 138K is currently not supported by the education version, and you need to download V1.9.9 or a newer version of the commercial IDE for use.
Lic can be applied on the Gowin official website, or you can use the online Lic service provided by Sipeed. In the IDE, select Float Lic and fill in the following information:
ip: 106.55.34.119
port: 10559
if the ip not work, try use "gowinlic.sipeed.com" domain's IP.
Install IDE Click me
Example code github
Other Learning Resources
- Free online tutorial: Verilog Tutorial (Learn Verilog)
- Free online FPGA tutorial: Verilog (English website)
- Verilog practice website: HDLBits (English website)
- Online Gowin Semiconductor reference video tutorials: Click here
Communication Methods
- Reddit : reddit.com/r/GowinFPGA/
- Telegram : t.me/sipeed
- Discussion forum: maixhub.com/discussion
- QQ discussion group: 834585530
- Leave a message directly below this page
- GotoGitHub project pageand submit issues
- Business email : support@sipeed.com
Precautions
Item | Precautions |
---|---|
芯片型号 | The specific model of the FPGA chip used by Tang Mega 138K isGW5AT-LV60PG484A Please select the package model PBG484A in the IDE. |
Static Electricity | Please avoid static electricity hitting the PCBA; release the static electricity from your hands before touching the PCBA. |
Tolerance Voltage | When using GPIO pin headers for external communication, ensure that the IO voltage is 3.3V. Excessive voltage will permanently damage the PCBA. |
FPC Socket | When connecting the FPC soft cable, please ensure that the cable is completely and correctly inserted into the socket without any deviation. |
PCIE Gold Finger | When testing the PCIE gold finger, ensure that both the host and the board are in the off or unpowered state to avoid short-circuiting the gold finger due to displacement during the insertion process. |
Plug and Unplug | Please completely power off before plugging and unplugging. |
Avoid Short Circuit | Please avoid any liquid or metal touching the solder pads of the components on the PCBA during the power-on process, otherwise it may cause a short circuit and burn the PCBA. |
Contact
Tang Mega 60K can meet different needs of customers in various scenarios. For technical support and business cooperation, please contact support@sipeed.com
Frequently Asked Questions (FAQs)
TBD
